| Frame |
aluminium 6061, quick-release 5 x 135mm, disc brake Post Mount |
|---|
| Fork |
SR Suntour SF19 XCE28, steel spring, Travel: 100mm, steel steerer tube 1 1/8", quick release |
|---|
| Shifting system |
Shimano Tourney TY300, 21 speed |
|---|
| Front derailleur |
Shimano Tourney TY300 |
|---|
| Gear lever |
Shimano EF505, shift / brake lever combination |
|---|
| Crankset |
Shimano TY301, aluminium, 24-34-42 teeth |
|---|
| Inner bearing |
FP-B908L, BSA |
|---|
| Rear sprocket |
Shimano HG200, 12-32 teeth |
|---|
| Chain |
KMC Z51 |
|---|
| Brake lever |
Shimano EF505, aluminium |
|---|
| Front brake |
Shimano MT200, 160mm, 2-piston disc brake |
|---|
| Rear brake |
Shimano MT200, 160mm, 2-piston disc brake |
|---|
| Tyres |
Mitas Ocelot, 54x584 or Mitas Ocelot, 54x622 |
|---|
| Rims |
XLC X-630 D-WALL, hollow rim, aluminium |
|---|
| Front wheel hub |
Shimano TX505 |
|---|
| Rear wheel hub |
Shimano TX505-8 |
|---|
| Spokes |
black 2.0mm/2.0mm/2.0mm, black |
|---|
| Handlebar |
XLC Topflat 720mm |
|---|
| Grips |
XLC MTB grips |
|---|
| Stem |
XLC Alu, A-head |
|---|
| Head set |
WTB NO.10 ED 1-1/8" SEMI INTEGRATED, aluminium |
|---|
| Saddle |
XLC MTB |
|---|
| Seat post |
patent, 31.6mm, aluminium |
|---|
| Pedals |
plastic, non-slip |
|---|
| Total perm. weight |
120kg |
|---|
| Wheel size |
27.5" |
|---|
